T-TYPE WALL BRACKET
Instruction Manual:
◆ Suitable for: supporting trays on wall.
◆ Fit for: diameter of wire from 3.5mm to 6.0mm, tray width from 100mm to 300mm.
◆ Includes: bracket x1, KK34-top x2, M6x20 bolt x2, M6 nut x2.
Description
| Part Number | Height | Length | Weight |
| PJ-CRP100 | 84 | 122 | 0.32kg |
| PJ-CRP150 | 84 | 172 | 0.34kg |
| PJ-CRP200 | 84 | 222 | 0.35kg |
| PJ-CRP300 | 84 | 322 | 0.38kg |
Instruction Manual:
◆ Suitable for: supporting trays on wall.
◆ Fit for: diameter of wire from 3.5mm to 6.0mm, tray width from 100mm to 300mm.
◆ Includes: bracket x1, KK34-top x2, M6x20 bolt x2, M6 nut x2.
Surface Treatment Technology
Explore Our Premium Cable Trays
Certified Excellence
Our cable trays adhere to the highest industry standards and hold trusted certifications like CE, UL, and E90 Fire Rated test.
Superior Welding
Our cable trays have solder joints, impressive load-bearing capabilities, and an outstanding welding strength of 3750N with a welding depth of 0.5-0.7mm.
Intelligent Protection
Our cable trays are thoughtfully designed with a 70° chamfer angle to effectively prevent cable damage.
Innovative Surface Solution
Our unique Zinc-Nickel Composite cable tray guarantees an attractive appearance with high corrosion resistance, prevents zinc-whisker formation.
Swift Delivery
We maintain substantial stock levels of conventional products , ensuring prompt delivery to meet your requirements.
